Pleased to announce the release of our new catalogue!

We are pleased to present our new catalogue.

The new catalogue breaks new ground in inspiring a new clear graphic structure. Cussons presents new products concepts and separating products ranges including images to improve readability and effectiveness.

Please download our new catalogue (high resolution) by clicking here or use the direct link below to our website.

New Cussons Catalogue

P6100 Hydraulics Bench and Accessories

Hydraulics Bench - Series and parallel pump

The Cussons Hydraulic Bench provides the basic services for pumping and volumetric measurement of water supply. Various optional modules are available to form a comprehensive laboratory facility which enables a detailed Mechanics of Fluids Experimental Course to be followed. The equipment is designed to provide a clear visual appreciation of hydraulic principles and has been featured by +BBC News  on the Open University Mechanics of Fluids course.

• Centrifugal pump characteristics
• Flow in pipes and pipe fittings
• Flow through orifices and over weirs
• Flow in channels
• Bernoulli's experiment
• Water flow measurement
• Hydrostatics
• Free and forced vortices
• Hydraulic machines
• Pipe networks
• Reynolds number

#hydraulics #civilengineering #reynolds #flowchannel #weir #pump #hydrostatic
For more information:http://www.cussons.co.uk/

P3210 Heat Transfer Bench with cross Flow Heat Exchanger

A range of experiments in the field of Heat Transfer has been developed for the basic Air Flow Bench to meet the needs of this growing area of study.

FEATURES

•  Large range of add-on experiments in heat transfer, air flow and aerodynamics.
• Well instrumented including dual sloping manometer, barometer and pitot static tube.
• Additional equipment easily and quickly fitted.
• Enables a series of forced convection heat transfer coefficients to be derived.
• Data logging outputs of heater current and voltage, surface temperature and air temperature available as an option.

PRINCIPLE EXPERIMENTS

• To determine the relationship between Nusselts and Reynolds numbers applied to a single heated tube positioned transversely to a stream of air.
• To determine the effect of change of diameter on the heat transfer coefficient to a single tube in cross flow.
• To determine the effect of change of position of the heated tube within a cross flow tube bundle.

P6510 NETWORK OF PIPES APPARATUS

The Cussons P6510 Network of Pipes Apparatus allows students to conduct a range of experiments on a system of interconnecting series and parallel pipe networks as well as fluid distribution systems.

EXPERIMENTAL NETWORKS

• Single pipe
• Two pipes in series
• Four pipes in series
• Two pipes in parallel
• Four pipes in parallel
• Series parallel network with 3 or 4 elements
• A 3 pipe series network with a parallel bypass
• A distribution system with 2, 3, or 4 branches from a common manifold
• A long distribution system with 1, 2, 3 or 4 discharge points
• A ring main distribution system with 1, 2, 3 or 4 discharge points
   #pipes #network #pipenetwork #bench #civilengineering #hydraulic #civil



  For more information:http://www.cussons.co.uk/

P7674 Ejector Bench

The principle of operation of an ejector is simple: a high velocity steam jet blows into the ejector throat and thereby produces a suction which draws a fluid into the throat at high velocity.

FEATURES

• Compact modular design
• Easy installation
• Comprehensive instrumentation
• Pressure test certificates supplied for major components
• Low capital cost

Steam Head Assembly

Mild steel steam header welded in accordance with BS2633 (1973) with a branch providing a steam supply to the ejector. The steam header is enclosed within a header box and fully insulated with mineral wool.

Certification

The steam header is pressure tested at 21 bar and is supplied complete with a test certificate.

Inter-Connection of Steam Benches

To enable steam benches to be linked to form a system utilising a common steam supply and service system, the steam bench is supplied complete with:

• An interconnecting back panel and student work surface.
• A set of 4 stainless steel flexible hoses for the steam and service connections.
• A section of aluminium clad lagging for the flexible steam hose.

#ejector #BS2633 #steam #ejectorbench #steamjet #lagging #ejectorthroat

For more information:http://www.cussons.co.uk/

P9010e Turbojet Engine Test Stand

Cussons Turbojet Engine Test Stand provides a fully functioning, aero derivative small jet turbine.

Turbojets are used as high performance jet engines in aircraft and to provide the core of the very successful turbofan engines used on the great majority of airliners.

Cussons Turbojet Engine Test Stand provides a fully functioning, aero derivative small jet turbine. The jet turbine thrust can be measured and outputs from up to 230N can be achieved. The unit is provided with a mimic diagram displaying the temperatures of the gas flow and engine pressure ratio. Air flow, fuel flow and rotational speed measurement mean that an energy balance for the engine can be undertaken.

EXPERIMENTS / LEARNING CAPABILITIES

• Demonstration of the Turbo jet principle
• Performance analysis of a Turbojet at varying power
• Temperatures air inlet
• Fuel inlet compressor outlet
• Combustion chamber outlet
• Tail pipe stream
• Ambient air pressure
• Air inlet differential pressure
• Compressor outlet pressure

#jetengine, #turbojet, #thermodynamics, #aircraft, #jetturbine, #turbine, #jet, #combustionchamber

For more information: http://www.cussons.co.uk/

P9235 SPECTROANALYSER

The Cussons Spectroanalyser 3 has been developed to measure low concentrations of nitrogen as an impurity in certain rare gases, and has found particular applications with high purity argon.

APPLICATIONS

• Measurement of trace amounts of nitrogen in high purity argon production and user systems
• Quality control of high purity/ultra-high purity argon cylinders

FEATURES

• 0-100 mV and 4-20 mA recorder outputs
• High and low level alarm contacts
• Analyser electronic self-check facility
• Design eliminates background interference

 TECHNICAL SPECIFICATION

• Ranges: 0-10 vpm and 0-100 vpm Nitrogen in Argon
• Display: Analogue meter
• Limit of detection: Less than 1 vpm
• Sensitivity: Less than 1 vpm
• Zero drift: Less than 0.1 vpm per ºC
• Cycle/response time: Continuous/90% within 60 secs
• Accuracy: Depending on calibration gas available as it is a comparative method that is employed
• Sample flow rate: 2 litres per minute
• Sample inlet temperature: 10ºC minimum, 30ºC max.
• Sample inlet pressure: Optimum 0.35 to 1.05 bar g; maximum 3.5 bar g
• Sample outlet pressure: Maximum 0.15 bar g
• Sample pipework: 6mm or 1/4 OD stainless steel and PTFE
• Analogue output: 4-20 mA and 0-100 mV
• Alarm contacts: Adjustable high and low alarms with both normally open and closed voltage free contacts rated at 250V, 5A, AC non inductive
• Electrical supply: 110/220V, 60 Hz or 220/240V, 50 Hz single phase

#Spectroanalyser #argon #calibrationgas #purityargon #nitrogen #Analyserelectronic
